Description :
Got a solo gig at the local coffee shop? Need to make a quick public announcement? Simple sound calls for the simply superb XENYX 802S, the Behringer mixer with everything you need to give an intimate setting incredible sound. The ultra-compact XENYX 802S mixers 8 Inputs (2 mic, 2 stereo + Aux Returns) allow you to effortlessly achieve premium-quality sound, thanks to the 2 studiograde, phantom-powered XENYX Mic Preamps and ultra-musical British channel EQ.
Specifications
Microphone Input:
Balanced XLR, discrete input circuit
Mic EIN (22 Hz-22 kHz) @ 50 : 132 dB, A-weighted
Frequency response Gain +10 dB: 10 Hz to 150 kHz
Frequency response Gain +60 dB: 20 Hz to 70 kHz
Gain range: +10 dB to +60 dB
Max input level @ +10 dB Gain: +12 dBu
Input Impedance: 2 k balanced
Distortion (THD + N) 1 kHz @ +10 dB Gain: 0.005%
Mono Line Inputs:
1/4″ TRS connector balanced
Impedance: 22 k balanced, 10 k unbalanced
Gain range: -10 dB to +40 dB
Max input level @ 0 dB Gain: +21 dBu
Stereo Line:
1/4″ TRS connector balanced
Frequency response: 20 Hz to 200 kHz
Impedance: 22 k balanced, 10 k unbalanced
Max input level @ 0 dB Gain: +21 dBu
STREAM Inputs (Analog):
RCA connector unbalanced
Impedance: 10 k unbalanced
Max input level: 10 dBu
EQUALIZER:
Low: 80 Hz/15 dB
Mid: 2.5 kHz/15 dB
High: 12 kHz/15 dB
Main, Monitor & FX Send Outputs
Type: 1/4″ TRS connector impedance-balanced
Impedance: 120
Max output level: 21 dBu
Phones Out
Type: 1/4″ TRS connector unbalanced
Impedance: 23
Max output level: 19 dBu/150
STREAM out (Analog)
Type: RCA connector unbalanced
Impedance: 1 k unbalanced
Max output level: 10 dBu
USB
Type: Type-B connector
USB Audio Data: 48 kHz 16 bit
UAC2 Class Compliant: stereo in/out
Power Supply
Power Consumption: 12 W
Adaptor input: 100 – 240 V~, 50/60 Hz, 0.5 A
Adaptor output: 18 V DC 1.0 A
